Description
Technical Parameters：
●Water Pressure———————————————-0.15—0.6MPa
●Water Temperature—————————————–5℃-50℃
●Water Turbidity———————————————–＜20FTU
●Inlet/Outlet—————————————————–1/2″or 3/4″F
●Drain————————————————————1/2″or 3/4″F
●Base————————————————————-2.5″-8NPSM
●Riser Pipe——————————————————1.05″OD
Product Characteristics：
■It adopts hermetic head faces with high degree pottery and corrosion resistance for opening and closing.
■No water passes the valve in rinse in single tank type.
■Reasonable design of the flow passage: Service→ Fast Rinse→ Backwash → Fast Rinse → Backwash →Service.
■It can be changed to be side-mounted valve with side-mounted connector.
■It can operate under pressure, without leakage.
Range of Application：
Residential filtration system
Swimming pool filtration equipment
Active carbon or sand filter in RO pretreatment filtration system
●Max Flow Rate————————————————-2 m3/h
●Suitable Tank Size (in)—————————————6″～10″
